Venn Var 37 TCD filament wound tubeless clincher disc brake carbon rim

The Venn VAR 37 TCD filament winding process utilises slit tape towpreg wound using two winding heads to accurately lay up the carbon fiber in an automated, computer controlled process. The use of preimpregnated carbon fiber tape allows us to use the latest resins that offer the optimal blend of toughness and impact resistance.

Venn Var 37 TCD rim profile





















The profile of the Var 37 TCD rim was developed to offer the best aerodynamics when used with 25-28mm tires and is part of the same family as the exceptional Venn Var 507 rim series. The external width of 28mm optimizes the airflow in combination with wider tires, while the internal width of 21mm ensures that the wider tires achieve a stable, round profile. The rim width also means that the rims are laterally very stiff while the filament winding process ensures that the rims remain vertically compliant due to the 45 degree fiber layup bias. The advanced CFD developed profile of the Venn var 37 rims ensures that their aerodynamic performance exceeds that of any rim in a similar category.

Venn Var 37 TCD aerodynamics





















Selecteer opties en bestel

Description

Manufacturing technology Machine filament wound
Brake compatibility Disc
Tire type Tubeless/clincher
Size 29″, 700c
Width 28mm external, 21mm internal
Depth 37mm
Rim weight 450g +/- 15g
Rider weight limit 110kg
Hole number 24 holes
ERD 566.2mm

Additional information
