Venn Var 35 TCC filament wound tubeless clincher rim brake carbon rims

VAR filament winding process utilises slit tape towpreg to accurately lay up the carbon fiber in an automated, computer controlled process. The use of preimpregnated carbon fiber tape allows us to use the latest resins that offer the optimal blend of high glass transition (Tg) temperature exceeding 240° C in testing , toughness and impact resistance. Var rims can therefore be used in challenging conditions where extended braking periods are expected.










The profile of the Var 35 TCC rim was developed to offer the best aerodynamics when used with 25-28mm tires. The external width of 30mm optimizes the airflow in combination with wider tires, while the internal width of 21mm ensures that the wider tires achieve a stable, round profile. The rim width also means that the rims are laterally very stiff while the filament winding process ensures that the rims remain vertically compliant due to the 45 degree fiber layup bias. The combination of these features results in very fast, safe handling wheels that can be used in any conditions.

Selecteer opties en bestel


Manufacturing technology Machine filament wound
Brake compatibility Rim
Brake track width 28mm
Tire type Tubeless/clincher
Size 29″, 700c
Width 30mm external, 21mm internal
Depth 35mm
Rim weight 460g +/- 15g
Rider weight limit 110kg
Hole number 20h front, 24h front, 24h rear
ERD 568.2mm
